• Multiple working modes to address your business needs: Default(Normal mode), VLAN(Secure mode), EXTEND(Surveillance mode)
• Support port traffic control
• Support for secure mode, all downlink ports can communicate only with uplink ports
• Up to 250m transmission distance on surveillance mode
• Support buffer optimization
• All metal housing, safe and reliable
| Hardware Specification | NSW2010-24T2GC-PoE-IN | |||||||
| Ports Type | 24×100Mbps PoE ports (RJ45)+2×1000Mbps Combo ports | |||||||
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x, IEEE802.3af, IEEE802.3at | |||||||
| Switching capacity | 8.8 Gbps | |||||||
| Packet Buffer | 4 M bit | |||||||
| Forwarding performance | 6.55Mpps | |||||||
| MAC | 16K | |||||||
| Max.Power | 390W | |||||||
| Weight | <4.2 kg | |||||||
| Cooling Fans | 2 | |||||||
| Mean Time Between Failure (MTBF) | > 50000 hours | |||||||
| Dimensions (W×D×H) | 440mm x 207mm x 45mm(17.3"×8.1"×1.8") | |||||||
| Operating humidity | 10%～90% (non-condensing) | |||||||
| Working Mode | Default (Normal mode) : All ports can communicate with each other, EXTEND (Surveillance mode): Transmission distance up to 250 meters, VLAN (Secure mode): Downlink ports can communicate only with uplink ports. | |||||||
