Hardware Specification	NSW3000-16T1GT1GC-POE-IN
Ports Type	16 x 10/100Mbps POE port (RJ45) + 1 x Gigabit port (RJ45)+ 1 x Gigabit Combo
Standards	IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab, IEEE802.3x, IEEE802.3af, IEEE802.3at, IEEE802.3az
Switching capacity	7.2 Gbps
Forwarding performance	5.36Mpps
Packet Buffer	4 M bit
MAC	16K
Weight	2.1kg
Dimensions (W×D×H)	440mm x 189.8mm x 44mm
Max.Power	265W
PoE	support POE
Max.PoE Power	Maximum total power: 250W
	Maximum PoE power for single port: 30W
	Mode A, 1/2+, 3/6-
	Mode B, 4/5+, 7/8-
Prior Ports	1 to 8
Cooling Fans	1
Operating humidity	10%～90% (non-condensing)
Storage Humidity	5% to 90% RH, noncondensing
Software Specification
Ethernet	Supports full duplex, half duplex, and auto-negotiation working modes.
	Supports port auto-negotiation rate.
	Supports port priority flow control.
	Supports a link aggregation group (consist of two uplink ports)
	Supports port flow statistics
	Supports enabling/disabling ports
VLAN	Supports both access and trunk modes; allows up to 32 VLANs with IDs from 1 to 4094
MAC	Support (up to 16K).
	Supports clearing the dynamic MAC address
POE	Allows to view PoE status and power.
	Allows to enable/disable PoE power supply.
Loop Detection	Loop Detection
QoS	Supports port rate limitation.
	Supports broadcast storm control.
Security	Supports port isolation (only for the downlink ports).
	Supports locking login IP address, up to 64 addresses can be locked
Maintenance	Supports N: 1 port mirroring.
	Supports unified software configuration, management, and search.
	Supports discovering the connected video devices and generating a network topology on the software.
	Supports device upgrade, factory settings restoration, configuration import, configuration export, logs export, and device restart on the software.
System	Allows to view the device name, device model, serial number, current version, IP address, MAC address, DNS, operation time, etc.
	Allows to edit and manage the IP address and device name.
	Supports single-user management, user authentication, and password modification.
	Allows to view other switches information on the same network, up to 32 switches.
	Allows to view the connected video devices information, up to 64 devices .
